10 strakes left on the port side
-
builder_Nick reacted to a post in a topic:
Wappen Von Hamburg by builder_Nick - Corel - 1:40
-
builder_Nick reacted to a post in a topic:
Wappen Von Hamburg by builder_Nick - Corel - 1:40
-
I’m getting closer and closer trying to add a strake each day. I might finish a side by early next week.
-
builder_Nick reacted to a post in a topic:
Wappen Von Hamburg by builder_Nick - Corel - 1:40
-
Thanks! I was nervous about planking this way, but I’m glad I did.
-
builder_Nick reacted to a post in a topic:
Wappen Von Hamburg by builder_Nick - Corel - 1:40
-
I also want to mention that I now have the instructions that I was missing! Model Expo was a huge help and contacted Corel about getting it. I received an envelope with the instructions and a note written in Italian. I’m grateful to finally have the images that the instructions reference.
-
Not too much to report. The planking continues on with each strake keeping me humble. I feel like my process is working well and that I’m seeing better results with each strake I complete. I have about 20 more to go before I reach the keel.
-
builder_Nick reacted to a post in a topic:
Wappen Von Hamburg by builder_Nick - Corel - 1:40
-
builder_Nick reacted to a post in a topic:
Wappen Von Hamburg by builder_Nick - Corel - 1:40
-
A quick update to show that I’m still progressing on the planks. I decided to try for more realistic scale lengths. I like the look of the joints and the variations in tone it creates. I also darkened the edges with a pencil.
-
So it begins... the first row of planking is attached on both sides. The plank bending around the bow went well for my first try. I’ll be getting plenty of practice moving forward.
-
builder_Nick reacted to a post in a topic:
Wappen Von Hamburg by builder_Nick - Corel - 1:40
-
The new stempost is ready to go. There are a few details to finish, but those are going to wait for later in the build.
-
Working on a template for the new stempost. The shape of the bow is a little different than the plans so I needed to make sure the template is good before working in walnut.
-
builder_Nick reacted to a post in a topic:
Wappen Von Hamburg by builder_Nick - Corel - 1:40
-
Glad to have you follow along. I was trying to figure that out too. It seems like it was well glued and then removed for some reason. I don't have the broken piece from the top, but the bottom part that connects to the keel was still attached to the keel.
-
builder_Nick reacted to a post in a topic:
Wappen Von Hamburg by builder_Nick - Corel - 1:40
-
Thanks for the compliment! It is an adventure.
-
The ports on the bow are unique as they are meant to be cut in through a crescent piece of wood without frames like the others. While probably a minor detail, I was pleased with the way the other ports looked and decided to give these two a similar treatment by making the openings bigger and creating custom frames. The first picture shows the over cut opening on the left and one of the frames installed on the right. I made the frames deep enough to get the inside and outside curves. The second picture shows the frames trimmed, sanded, and installed. All ports on the gun deck are now uniform with clean, accurate, square edged frames. Now that the ports are installed, I am going to give the ship a once over to do some fairing. I need to figure out what was happening around the bow that caused some deviation from the original plan. As the pictures show, there is a slot cut in that I don't see mentioned in the instructions or any pictures of other builds I have found. I am hoping it was only for additional strength. My concern is that it will bring the stem back and interfere with future alignments. I may adjust my new stem that I am milling to accommodate the slot depth. There is also some strips of wood added and saw marks that make me think some fairing had taken place to correct the shape. I am going to do some research into fairing techniques and then get this ship a step closer to planking.
-
While hunting for reference pictures on the web, I stumbled across an image of the instructions. It clearly showed a technical drawing reference that I don’t have. Time to figure out how to get a copy.
-
I was looking through the box and found the stempost. It appears to have been glued on the bow and then removed. I’m not sure if it was intentionally or accidentally removed. It suffered some damage and doesn’t seem usable. I have some walnut to mill a new one. The stempost doesn’t appear in the instructions yet, but I like the technique of leaving a rabbet to tuck planks cleanly. I’ll be doing a little more research as I plan out how to mill the stempost and incorporate the rabbet.
