  1. Siggi52
    Thank you, Nils
  2. Siggi52
    Thank you, John
  3. Siggi52
    Thank you, Patrick
  4. Siggi52
    Thank you, Marc
  5. Siggi52
    Hello, and many thanks for your likes today I set in the last knees and the first side frames, as W. Dammann they named, up to the gun wales.
  6. Siggi52
    Hello, today I build in another 8 knees and only 8 are left 😃 Only to show you the dimentions of the knees. When all went right, I takes half an hour for such a knee. But that happend rarely The planks I build in between those points are in reality parts of the beams, means it is one pice of wood.
  7. Siggi52
    Hello Dick, with the rocker in the keel you will have no trouble with hogging. That is statics. I did't heard anything about hogging from viking ships. My ship is at least, now that the frames are build in, realy stabil.
  8. Siggi52
    Hello and many thanks for your comments and likes, today I finished the first 10 knees. Only 24 left 😟 That was't an easy task, but as I had established a routine, it worked well.
  9. Siggi52
    Thank you, Chuck and John
  10. Siggi52
    Hello, there was not much action at the shipyard the last time, but at least I made the mast and yard for the ship. Next on my list are the inverted knees 😐
  11. Siggi52
    Thank you Albert
  12. Siggi52
    Hello, I set in all the deck beams and most of the stantions. At the second picture you see, that the underwater ship has it's broadest pard one or two meters infront of the mast. The beams are at least 97-100 cm apart from each other. Greatings also from the ships cat. He is getting old now (18) and enjoys the warm weather we have here the last days.
  13. Siggi52
    Thank you Ian and Chuck. Chuck, the nails/rivets are pencil marks 😇
  14. Siggi52
    Thank you Keith
  15. Siggi52
    Hello, thank you John and all others for your likes. The mast step is ready and installed. Now my fingertips have to regenerate for some time 😉 And here with the deck beams installed. As the next thing to do, I think to instal the other deck beams.
  16. Siggi52
    Hello, today I found some time to work at the shipyard and build the mast step. There are some knees left to build, but tomorrow is also a day. And here he is fitted in. There is a little gab to the left, but the knees will cover it later. Only the outer deck beams are fast at the moment. I needed a high fore the mast fish, who will follow next. With the beams I made a short cut with there ends. You would't see that later.
  17. Siggi52
    Hello John and Richard, thank you. Richard, because I could't build the ship like the Vikings, I build the planks over a plug and take the frames also from that plug, as seen in one picture. And yes, I had to fit the planks to the frames because they sorted themself into a comfortable way and did't stay in the way they where build at the plug. But it was not soo much I had to correct.
  18. Siggi52
    Hello, the last two day I was pretty busy at the shipyard. UPs, and where is the ship? 😄 All the frames are installed. The next days I think, I must concentrate my work more onto my house and garden. During that time, the ship could settle before I install the bitis (deck beams)
  19. Siggi52
    Hello, and many, many thanks for your comments and likes Last week we had here an outstanding wether with much sunshine, so I was't very often at the shipyard. But today it rained, and there was really action at the shipyard. I build and installed the first frames. First I would cut the undercut of the frames like those at the originals, but that was too dangerous for my fingers and the frame itself. So I decided to file it insted. The form of the frames I took from my plug Glueing them in was the next challenge. Because, the hull was a little out of shape and I must work with a little brutality and big clamps 😉 For the next frames I took a third pair of clamps and all went well.
  20. Siggi52
    Hello Richard, the planks are glued together. I used white watersolvent wood glue. So I could make later easier corrections. What I had to due more often. The clinker nails are only pencil marks.
  21. Siggi52
    Thank you Chris, I hope that you are right. At noon I was't so sure. 😏
  22. Siggi52
    Hello, and thank you for all the likes. The two bulkheads at the bow and stern cost me a lot of nerves. You have nothing to lean on. It's all free floating. But now it's done. Here the one at the bow. And here the one at the stern. This one was a lot more complicated, because it has to hold also the rudder. When I dryfitted them, they fit all perfect. But when you get a little glue on them, nothing fits. 😐 So all out and try again. The lower parts you would't see later, so I'm here a little more generous with the seat. And here the carpenters from the Tiger have a look what I'm doing so all the day
  23. Siggi52
    Hello, there is not so much happend here. I draw the nails also from the inside of the hull and glued the cleats in, for those frames you may see later. They are 0,6 by 0,8 mm and 3.5 mm long
  24. Siggi52
    Thank you John
  25. Siggi52
    Thank you Keith
