Clamp boards are fully installed now. If I had to do it over again, I would install the spacer batten strips with the hull in the jig, but the clamps are better installed with the hull taken out of the jig.
-
The 3/4'' wide binder clips from Staples are fantastic for model ship building. They open to about 1/4'' - maybe 5/16.'' I used them to re-glue most of the frames to the clamp board. The frames popped loose when I detached the batten spacer that was 'tacked' in place with glue.
-
My temporary spacer batten strips for clamp placement [see figure 1-12 in the instruction manual] are now in place and attached to each frame with glue. (I plan to separate them later with a zona saw or razor knife) But I see the frame tops are not in line with each other. The frames should have come extra long so we could trim each one down to the top of the batten. Just like when you build a wooden deck out of 2x6's, you run them extra-long, snap a chalk line and trim them perfectly flush. And yes, frame 4 is especially short, as noted by other modellers. I had to elongate it with a half-lapped extension using scrap from the laser sheet that the frame was taken from. It took quite a while to make it fit well. Maybe a simple butt joint would have sufficed. But I wanted to maximize glue surface for strength.
-
As I tack the temporary clamp spacer board to the frames, I find it necessary to release the frames from their battens to which they too, were temporarily tacked. Battens are the little strips of wood used to prevent any motion of the frames perpendicular to the keel during the framing process. They were adhered to the jig surface with a tiny amount of glue and the the frames with another tiny amount of glue. The notches in the jig prevented any fore-aft motion of the frames.
-
FYI The PDF template mentioned above is modified to better grab the first few frames.
-
Here is my template. But you need to bring it to Staples if you do not have access to a printer that handles ledger size prints. EMMA C.BERRY jig template rev. 4-19-22.pdf
-
Installation of temporary batten to help accurately locate the hull clamp board. Some carving of keel-side bevels of the the first few frames was needed for glue contact area of both the temporary batten as and the forthcoming hull clamp board was needed. Dabs of PVA glue was applied to the frames before setting the battens in place with spring clamps. I pre-bent the battens by running a trickle of hot water down their length in the sink in order to soften them. Transom was installed before the batten work was done. The trick with the transom elevation is aligning its bottom bevel with the 'plane' of the frame's bevels.
-
Had a hard time coming up with a method for clamping the keelson unit while the PVA glue cured. I ended up using wire. There was a lot of sanding/carving/shaping involved with getting decent contact areas for the glue.
-
Clamping the glued-up rudder box to the keel. See Andrew Bodge's ECB build log for details I contributed as to the proper positioning of this assembly.
-
All frames are in place.
-
Frames 4 thru 23 were pre-assembled on a flat surface marked with frame width measured from blueprints.
-
Frames 1 thru 12 in place. Jig notch depth improved.
-
Frames 2 and 3 are in place. Jig notches just barely caught these frames. It was not easy designing the jig's cutout. I feel lucky it worked out OK.
-
To create the frame bevels, I mounted a Dremel sanding drum into a drill press. Using a hobby knife seemed too risky. Sanding is easier to control. It is also easy to remove char with this setup.
-
To mark the frame's bevel lines, I started using a french curve. But it was smarter to use the port side frame as a guide to mark the starboard frame and vise-versa. Just eyeball the location from the blueprint. I opted not to produce the keel-side bevels. We will see if I come to regret that later.
-
Frame 1 laid-out imperfectly in the dry-fit- so I had to sand the face that mates to the keel to true it up.
-
Marking and carving out the rabbet with a snap-off blade. I dreaded this step thinking the grain would force the blade out of intended path. But the grain is almost as soft as the non-grain part of basswood.
-
Using thin wire to secure glued sternpost to the keel.
-
Shaping the half-round profile in the rudder post edge using sandpaper wrapped around a small piece of roundstock. To center the 'tool' on the edge, I created a rabbet using a table saw with blade set at 45 degrees and barely protruding above the table. It was overkill - for sure.
-
Andrew - Thank you and Happy Easter
-
Andrew - I just posted my ECB build log on this forum. But where can I learn how to insert descriptions/captions between each photo?
-
My son bought me this kit, as well as the 18th Century Longboat previous build and the Willie Bennett next build to act as a distraction from following political news coverage too obsessively. I have not built models of any kind since I was a kid. And so, here I am, back at the modeller's workbench - nothing more than a small desk already cluttered by computer monitors and a printer. As I surfed for tips and methods for assembling the ECB on various sites, I stumbled across a sensible alternative to the kit's overhead gantry - a raised platform with a cut-out of the hull's profile. And so, I scrapped the gantry and built the jig.
-
Absolutely. Please guide me.
-
I wonder if there is a way to attach the photo so viewers can more deeply zoom into it.
-
Hi Andrew By eyeballing the bevel line location from the print and running a .7mm mechanical pencil over the wood using my middle finger as a guide at the edge, I was able to make a decent line when it needed to be parallel to the edge. When the line had to start bending away from being parallel. I used a french curve. Next, I chucked a dremel sanding drum into my bench-top drill press and gingerly free-handed the cut with a follow-up of some normal hand sanding. It looks good to me. I am not sure i want to pursue the inboard bevel for this project. For drawing the rabbet lines on the keel, I used translucent sandwich wrap paper, pinpricks and the french curve. Now, I need to practice different methods for carving out that material. Here is a photo of the ECB I took in 2013......
