Video 6 is complete with the exception of the flour sacks. I'll address the sacks later as I'm still thinking of options. I mixed the sand with PVA glue in a mason jar. This made me feel less rushed to apply to the model since I could seal the jar if necessary. I was a little concerned about how the sand would work out but after curing overnight the result is like concrete. Nothing will move. I was also concerned that there wasn't enough sand to complete the ballast as shown in the video but it turned out there was plenty and I had a small amount left over. As for the barrels, I used a sharpie for the rings and and gave them a bath in poly sealant. I put a spot of PVA on the barrels contacting the sand and pushed them down into the wet sand mixture slightly. All barrels that sit on wood or on top of other barrels were glued down with clear Gorilla glue (not CA). This glue takes a long time to set but once cured nothing is moving. I followed the positioning of the barrels in the video to some extent but not exactly. There a few barrels left over which i set aside. Not sure if there is a need for these later on in the build. Next up in video 7 are the deck beams, wiring and lighting. A little nervous about this as it will test a skill I don't really have, soldering. The soldering will need to be neat and not lumpy. This will take me a while so I may also work on the orlop deck structures at the same time. Thanks for looking!

Thank you!

The first part of video 6 is complete. All support posts are installed. The video calls for very specific heights for each post and I made each post to that height. I'm not sure if that will be the correct height for my model but I can shorten them later with a set of very sharp nippers if needed. A small jig is provided with the kit to help get the correct distance between posts where there are three posts across the frames. I tried this with the first frame but it was getting in my way more than anything else. I abandoned that and just determined the correct distance apart for the posts. I used a brass nail in the bottom of each post as seen in the video and did my best to get the posts aligned correctly. Next up are the flour sacks. The kit provides a template to make these from paper or cloth I guess. I feel like this would have been a great 3d resin part. I'm going to skip that step for now while I see if I can find some 3d parts that will work. Next up are the barrels, a part I don't recognize (part H25 in the kit) and the ballast material.

I signed up for their 3D experience/creator home online version. Its like $55 a year. Just got a 3D printer and i have no clue what to do with it so far.

I feel your pain.

Video 5 is complete and this completes the primary structures in the hold. However, there quite a few details yet to complete the hold, such as support posts, flour sacks, barrels and ballast. This is covered in the next video. In addition, the lighting will need to be addressed. I haven't used lighting on a ship model before but this model seems to need it. I followed the order of assembly for the bow storage as seen in the video. I test fitted everything along the way. Some adjustments were needed along the way, again paying attention to the need to clear the deck. I glued the storage in before adding the final wall which is farthest to the right. There is a step up to that part of the decking so I wanted to make sure there was a good fit. Here are the other details that are added to the front compartment of the bow storage. Installed. The orlop deck doesn't have an opening that corresponds to the ladder but there is what appears to be a hatch cover there which you could open up if you choose to do so. I also installed the side walkways. This wall is just aft of the bow storage. The video would have you add the support posts after gluing the wall in but there is no way I would be able to see well enough to do that. I attached them before gluing the wall in. Just needed a little trial and error to get the proper length of the supports. Complete.

Its a beast.

I cast my samsung phone to my big screen TV and use the phones camera to view small things.

Thanks Nearshore. Its definitely a challenge but if I can do it, you can. A big plus to making these parts is that if I screw one up then I can just make another. And, imperfections will be hidden nicely once the decks go on.

Completed the final stern parts and stained the hold. Stain turned out a lot darker than I expected but its probably more realistic. This wall needed to be 7 mm behind the frame so I used a spacer. This is the detail added to the stern hold. The worlds smallest ladder is at the end of the walkway. The ladder was almost scrapped as I just couldn't see it. I called in an assist from the calvary. Its hard to see even now. The wall is glued in place as well. Here it is after adding the ledge to the wall and staining. Looks rustic. This completes video part 4 except the side walkways which I'll work on next. Moving forward to the bow hold. I glued in the small decks. These are the templates for the bow hold, there are many. This is probably the most complicated structure to build. The smaller set of templates is a wall that sits aft of the bow hold. I test fit the deck to make sure there were no conflicts and all is good. It confirmed my suspicion that most of this will be nearly invisible once the decks go in. Thanks for looking!

Pressing on to the rear compartments. I deviated from the build method in the video for this area. I just couldn't figure out how to assemble in that sequence and guarantee the finished structure would fit. Here I am checking the templates keeping in mind that the height is critical to ensuring the decks will fit on top properly. I temporarily positioned a couple of the deck supports to help with that. These parts are technically all the same shape. Here is the sequence of assembly I chose. I made the back wall first and then attached the two walls seen here along with the walkway. This helped me make sure they would sit perfectly on the deck. I glued these in here. Then i made the forward bulkhead and glued it on. And then made the last wall and glued it in. And finally made the last two parts and glued them in. From here I'll do some clean up and then there are two knees that are glued inside this area and a set of steps that lead up to the walkway. There is also another bulkhead to make just ahead of this area. The template is in the pictures. I will also get some staining done.

Sorry to hear that. I do understand the vision struggle.

I finished the well and the shot locker. It ended up being more of a challenge than I expected, particularly the top of the locker. This was probably the the simplest structure to build. to build but maybe not. Again, not glued in. I'm moving it out of the way for the next structure. I haven't stained the hold yet but will do that soon. I plan to use an oak stain since the majority of the ship was constructed from oak. I don't have any so need to get some. The video would have you make the steps next but I'm moving that to later. Template for that is here. Instead, I'm going to work on the stern storage. This is a bit complicated. The picture below shows what this should look like. The video would have you assemble this entire structure off model and then drop it in. Will need to think about this very carefully. There is no drawing of this structure either. This also requires that a piece of decking be glued in. This was the easy part. Note the mast locator. I'm having a vision of the mast passing all the way down through all the decks into that location hole. It does line up well with the notch below due to the locator notches. Here are the templates for this stern structure.

Thanks Bob

Update. Started work on the hold structures. This is the hold assembly drawing provided with the kit. There are no 1:1 drawings of the hold structures other than the templates. Starting with the pump well. I made the first two parts. I only used the "A" template as the A and D templates were virtually identical. I checked each template against there finished location and to make sure of the correct fit. As mentioned earlier, I glued the templates to cardstock and then glued enough planks together for each part. Here are all the parts for the pump well. I made sure the parts matched each other correctly. I used various tools to cut them out. Jewelers saw, Dremel scroll saw, exacto blades. It is necessary to make the door as well. This was a little troublesome as it was difficult to keep it from breaking, it took a couple of attempts. I ended up cutting out the window first and then the door. Glued all the parts together. Need to pay attention to the video for the correct orientation of the parts. The final well in place. I'm not gluing anything in until all the structures are made and placed. The position of some of them is critical to another structure later on so some adjustments may be necessary. Its necessary to make sure the proper fit of the deck cross beams as well. I made the slots in the structure a little too wide as its otherwise difficult to get the cross beam in. It does appear this cross beam is cut later. Its also important to make sure the height and shape of the structures in the hold don't interfere with the deck installation. It will be hard to see any of this later once the decks go in. This is actually the second pump well that I made. I didn't like the first one. There is a shot locker that attaches to the back of the well and here are the templates. Working this next.
