James H

Pavel has kindly sent me some extra photos of this kit development. I'm told this will be released close to the end of May, give or take.

Nice to see you're importing OcCre to North America. Welcome to MSW!

I'll be following this one!

A single fittings box is included. This kit has many cast metal features, such as the black swan, obviously! The latter is cast in three parts (body and two wings). Also note the name plate, anchors and stocks, lanterns, ship's wheel, and unusually, the mast cap squares. Gratings are supplied as combs, as is traditional, and brass wire is included, for things such as mounting the lanterns. Three spools of rig cord in arm brown are included, but this is only to pack out the remainder of the compartment, as the rest of the cord is supplied in an envelope. Also here are the rigging blocks and deadeyes, belaying pins, and other wooden details such as barrels. A good number of brass pins are included too, as are pre-formed brass rudder hinges. I did mention an envelope. This contains a whole suite of pre-sewn sails and the remainder of the rigging cord, in both natural and dark brown colours. Cord size is clearly printed on each spool. There is actually another envelope that lurks at the bottom of the box so that it's kept flat and less likely to bend. This contains a large, single sheet of photo-etch parts. Numerous are the gallery parts, window frames and bulkhead doors from the quarter deck. You'll also see scroll decor, and most unusual are the ladders which are typically made from timber. PE quality is every bit as good as that found in other contemporary kits, and the connecting gates are small enough that only a little pressure will be needed to remove them from the sheet. Instructions All instructions are supplied in the kit, but they can also be found online, should you want to study them on your computer before the next bench session. These amount to 63 colour-printed pages which detail everything in photographic form apart from the masting and rigging drawings. These are supplied as line drawings. There are NO extra plans included here as they simply aren't needed. Everything is in the manual. Here you'll also find the sheet maps so all parts can easily be identified. Conclusion This kit is very similar to the Artesania San Francisco that I built as my first ever wooden model, so I don't doubt that a relative beginner should be able to tackle this build, but I would suggest some experience beforehand, or at least in another modelling genre...simply so the modeller has a little focus and understanding of how to approach a build that contains different media. The model is also presented at a good price point too, and will doubtless appeal to those who have a love for pirate ships, but want to build a legitimate wooden kit of such a subject! The Black Swan also isn't 'too' large, relatively speaking. She's 613mm long, including bowsprit, and 585mm tall. If you want to sit her on a shelf, note that she's 257mm wide, so not too imposing. My sincere thanks to OcCre for sending out this kit for me to review on Model Ship World. To buy this kit direct, click the link at the top of the article. ALSO... If you need a paint set to go with this kit, OcCre have their own acrylic set. This can be bought HERE for £25.99. In here you will find two 50ml bottles containing walnut dye and satin varnish. The remainder are 25ml bottles. The supplied colours are gold, black, white, bitumen, and lastly a bottle of primer.

1:75 Black Swan OcCre Catalogue # 12012 Available from OcCre for £215.99 During the golden age of piracy, the Black Swan sailed the perilous waters of the Caribbean, leaving behind a trail of fear and admiration. Under the command of the ruthless Captain Tom Leach, this legendary ship raided Spanish trade routes and boldly faced fleets that tried to stop it. Its dark silhouette and black sails billowing in the wind were symbols of defiance, freedom, and adventure. OcCre's kit is a fictional vessel, inspired by Rafael Sabatini's novel of the same name, and the 1942 film. "From the coasts of Jamaica and Tortuga to Hispaniola, this ship is one of the most emblematic figures in the naval history of the Caribbean." The kit OcCre's kit is packaged in the same size box that Fram used, and several other of their kits that I've looked at here. This is a generic package, with a cutout that showcases the clear plastic fittings box. A large product label is fastened to the rest of the lid. When the lid is lifted off, the lower carton is folded inwards on itself to secure the contents. All of the timber/ply sheets are sealed with cellophane and didn't appear to have any warp or twist in them. The first sheet out is quite obvious. You can see from the MDF sheet that there are ten bulkheads along its length. The bulkheads are on two separate sheets and are made from ply. A few other parts are on these sheets too, such as the mast steps and various fairing blocks. One sheet here contains the parts for the cradle/display stand. This is made from ply. The top sheet contains the prow, keel and rudder post. This is produced in solid timber. This sheet of ply holds the four deck sections (including beak deck), and the various parts that go together to make the ship's launch. This is the sheet which holds all the details, such as rails, cannon carriages, etc. but also things like the mast tops and the lower run of cannon ports, on a single strip. Also on here you'll see galleries, channels etc. Laser cutting is excellent. Notice that these sheets don't have part numbers engraved. You'll need to cross reference the instructions for those details. Single piece upper bulwarks are supplied in ply. The quarterdeck upper edge has the ports with a temporary piece in situ so the edge stays straight during the most vulnerable part of the hull construction. Other ports are completely filled and just need the centres cutting loose. There are three packs of timber strip/dowel in this kit. The hull is planked in lime and then the dark, thin veneers are applied. I feel quite nostalgic when I see this as my San Francisco kit was constructed in the same way. The strip wood and dowel are nicely cut, with no fuzzy edges or warp in the parts.....quite important for the dowel! .....more soon.

With the front screwed into place, the unit that the instructions call the 'diverging room' is now screwed to the rear of this, complete with another bearing. I'm not convinced about that unit name, but hey, it all fits together very, very smoothly. The outer duct shell is now screwed onto our assembly. Of course, this aligns with the cutout in the main unit. The five stage compressor and high pressure turbine housing is now clipped into the shell, again using a little prising of the plastic, and this unit is slotted into the main jet engine, ensuring alignment. This unit is called the 'tail power module', which is a good description as this is where the engine will derive its power, strangely enough! This fits in a certain way, so the metal power contacts are positioned as in the second picture down. Finally, the tail cone is screwed into place, and that is it! The base unit comes complete with a set of batteries. The switch is also on the underside, which isn't really the best design as you need to remove the engine from the base to operate the switch. With the switch 'on', the engine is sat on the base, making sure the contacts on the engine seat with those on the base. The engine is immediately powered. Here you can see the engine in operation with the fan blades blurred. Also, the tail exhaust has red lighting to give a sense of power. There is no sound on this model, but I'm glad, to be honest. Conclusion Without a doubt, this is the simplest and quickest engine I've built so far, but that's no bad thing. This model was great fun to build and there's still a sense of satisfaction to see it operating. If you want a relatively cheap, dead simple to build, and very attractive little project to sit on your shelf or desk, then this is defintelyone to go for. A total novice could build this with no issues. The overall quality can't be faulted, and I really do recommend this gorgeous little model! My sincere thanks to EngineDIY for sending out this kit for review on Model Ship World. To buy directly, click the link at the top of this article.

1:18 WS-15 Turbofan Engine - SKYMECH - via EngineDIY Available from EngineDIY for $89.99 The Shenyang WS-15, codename Emei, is a Chinese afterburning turbofan engine designed by the Shenyang Aeroengine Research Institute, and manufactured by the Shenyang Liming Aircraft Engine Company. The WS-15 is intended to become the main engine of the Chengdu J-20 stealth aircraft, enabling it to super-cruise, improve its range, manoeuvrability, and upgrade potential for future weapon systems. It will eventually replace the Shenyang WS-10, which currently serves as the interim engine of J-20, while the WS-15 is being refined. Delivery of the Chengdu J-20B fighter aircraft, which will feature the new engine, to the Chinese armed forces could begin in 2025. Development of the WS-15 afterburning turbofan engine began in the early 1990s. In 2005, the engine performed successfully on the testbed. An image of the core appeared at 2006 China International Aviation & Aerospace Exhibition. In 2009, a prototype achieved 160 kilonewtons (36,000 lbf) and a thrust-to-weight ratio of 9. The thrust target was reported as 180 kilonewtons (40,000 lbf) in 2012. Abridged from Wikipedia The kit This is a surprisingly lightweight package with very simply line illustration and 'Jet Engine' given as the product name. The website does show this to be the WS-15 turbofan engine as mentioned above. Opening the box reveals just two deep trays of parts for this build, and unlike the Trent-900 I recently reviewed, there are more pre-built assemblies in this kit. In fact, the whole model took about 45 mins to build, and that's including my photo and test time. Don't let that out you off though, as this is a fun build! All parts are made from 3D printed plastic, and in various colours. There are a number of print lines, but to be fair, they don't detract, with parts made in various metallic colours. Also included are some screws and a screwdriver. The only parts that aren't plastic are some bearings to help smooth operation. The instructions come in the form of a simple printed and folded sheet, with only ten stages from start to finish. These are very simple to follow and will present zero problems for the builder. Work begins on the 'three level fan' unit. This is supplies a complete unit, and you simply need to screw the main shaft onto it. The outer housing for this unit is now fitted. All I did to fit this was gently prise the housing, and the fan assembly popped into place very easily. As you can see from the photos, the 3d printing is exceptional and looks very good. The air inlet assembly is now screwed into place. Note that this has a bearing which provides smooth drive at the front of the engine. More in a moment... ssss

I don't, unfortunately. I also don't have the ability to 3d print.

I think somebody mentioned those to me but they aren't defined enough. The rivet heads are quite shallow. I used the same transfers on a spitfire I built about 10yrs ago.

It's outstanding!

Exactly, that's why I'd ideally want something I don't need to shape and doesn't need to be treated. I'd give up the will to live if I needed to paint 1000+ rivets 😆

Cheers. That's exactly the sort of thing I'm after, but the cost is prohibitive. They want £8.80 for only 60 rivet. I probably need a couple of thousand. I've not counted, so even if only one thousand, it would be expensive.

One thing I'd like to do with this model is to add the nails to the outside. This will need a LOT of nails. The best thing to use would be domed resin rivets, preferably in black resin. These would be perfect for something like this. A ship like Oseberg would have nails spaced about 200mm apart, equating to only 8mm apart on the model. So you can see I need lots of these. Question...does anyone know where I could get something like this? I don't want to use blackened brass nails.

It's been almost 2 weeks since my last updates, and this might not seem like a lot, but I've certainly put a lot of hours in. The more visible things are the construction of the mast base, and also a full set of deck sections. Less obvious are the small changes and tweaks I've made to the hull, here and there, just so I'm happier with it. The mast foot is made out of several laminations of beech. All of these are glued up so there's a slot in the middle. What I did do was fill that slot with scrap timber and then drilled and reamed out the 9mm hole on a milling machine. Here you can see the mast base, sanded smooth to remove all the char. you can see it still needs shaping. Also here are the stack of deck sections, all finished wit 320 grit sand paper and then tweaked so they fit the hull. There are, in certain areas, very minor differences, so the deck sections are specific to their position. The edge margin timbers are bevelled on the underside so they don't foul the hull inner sides. The deck sections are provided as just that....sections, but you need to snap them apart like blocks of chocolate, then remove the edge char and bevel the top long edge. These are then glued back together to create infill sections for between the bulkheads. A little bevelling here and there, and they fit very well. The finished sections are bowed across their width, as you'll see, but they sit nice and flat with a gentle push. There are two paper templates. The first one dictates the upper profile. This is sat on and then traced. The assembly is then cut on a Dremel Moto-Saw. The second template is then traced. This creates the outer zone that needs to be shaped/rounded to finalise the shape. Here you see the mast foot sat in place, complete with the beech mast release part which has been soaked and clamped to the foot, to create that curve in the part. Also notice my bowed deck sections. They'll be just fine when glued down. The next job are some final woodwork tweaks and then onto some airbrushing.

I hope you'll do a build log for this.

Very impressive!

Oh, I do have a few more photos, showing one of the towers installed...

Yes, the paint set is on the site. He has a YouTube video explaining how to achieve that look.

I haven't done any painting yet.

I've been sent a few more photos of the progress on the Nef. This looks so beautiful.

Not an 'introduction'. Moved to correct forum area.

If you are thinking go getting this kit, I just added the product to the Vanguard Models website for when the product is near. I'm sure Chris could tell you a little more about ETA.

I do have to also add that the planks above deck level are properly cleaned up both inside and out, to remove any char and scorching that would impair the finish. All the others, as you can see deeper in the hull, are left as they are.

Planking is done!.....almost. You need to be real careful when planking. It's not a hard model to plank, and it's inevitable that you'll likely need to adjust the bevels a little. The planks are also supplied in a number of pieces each. What matters is first of all accurately fitting the temporary prow side facings. These will be key to making sure that each plank sits accurately on top of the other at the prow, and stack up to the correct height when it comes to the 10th row. That is, the last plank will sit neatly into the remaining gaps at the top of the temporary prow facings. Does that make sense? Ok, here we go. You can see here that the variation in the colour of those alder keel parts now doesn't matter. They are all covered up. You get an idea of how the sections are fitted, here. When it comes to working my way around the prow, I do multiple test fits and trims before I commit to glue. At that point, I only glue the prow too, then clamp. When set, I work my way around the bulkhead and use lots of clamps until fully set. This process isn't at all difficult, but it takes time to do methodically so that you get the best outcome. I'm not saying I did things perfect, but despite me being supercritical of my own work I'd give a generous 9/10. That is generally due to Pavel's excellent design being closely followed, especially on the tutorial videos on YouTube. Here is the hull, planked up to the 10th plank. At this point, I ran all the way around the exposed deck beams/ears and softened the edges. I should've done that before building the hull frame, but it wasn't difficult to do. You will notice one mistake I made.....the furthest bulkhead with ears....the infill part has the part number facing inwards, meaning it'd be seen when the model is complete. I'll come up with something to hide that. I put them in that way to neutralise the kerf between the bulkhead and infill, so my mistake! Here's the obligatory underside shot. You can clearly see where planks have been kerf-jointed so the grain runs true to the plank flow. I did have one joint 'pop' when planking, but that was only because I snagged it and strained the joint. There are just two more planking runs to fit, but these won't be fitted until I start to add stain to the interior. The reason is that it won't be easy to add the various stages to the stain if those planks are running between the bulkhead ears. In the meantime, I might make up the floor sections and do some test fitting before planking is finalised. Until next time...

Just a quick note. Fritzlindsay is another account that Allanyed set up after his banishment from here last year. He's now been restricted from posting.
