allanyed Posted February 29 Share #121 Posted February 29 At your scale, the method of assembly of the ratlines themselves makes sense but how do you secure/wrap the shroud pairs around the mast? What is the spacing from ratline to ratline? Many thanks Allan Quote PLEASE take 30 SECONDS and sign up for the epic Nelson/Trafalgar project if you would like to see it made into a TV series. Click on http://trafalgar.tv There is no cost other than the 30 seconds of your time. THANK YOU Link to comment Share on other sites More sharing options...
Admiral Beez Posted February 29 Author Share #122 Posted February 29 2 hours ago, allanyed said: At your scale, the method of assembly of the ratlines themselves makes sense but how do you secure/wrap the shroud pairs around the mast? What is the spacing from ratline to ratline? Best I can tell there is no wrapping, instead the top of the shrouds are glued in place beneath the top platform. I might add a little rope to appear that it's wrapped over the mast head. The spacing from ratline to ratline is about 2.75 - 3 mm, which at 150 scale would put them at about 41 - 45 cm apart at full scale. My one concern is getting the bottom of each shroud to line up with the matching line in the chain-whales, as they don't seem to line up with the holes, though the dead-eyes may hide any issues. Quote Link to comment Share on other sites More sharing options...
Admiral Beez Posted March 1 Author Share #123 Posted March 1 (edited) Shucks, I cut the top off the shrouds at the wrong spot, so there’s not enough material once I put the lowest rat line above the ship’s rail. Also I don’t like the alignment of the shrouds to the chains. Before I glue it again I’ll confirm the alignment. So, we start again. That’s okay, I call this the Learning Ship. Edited March 1 by Admiral Beez Mr Whippy 1 Quote Link to comment Share on other sites More sharing options...
TomRigg Posted March 1 Share #124 Posted March 1 Maybe too late into your build with the masts made up. But looking at the way that machine works could you do both sides at once? E.g. Lower mizzen shrouds onto mizzen mast looped over at the top . Then fix fighting top and topmast. Then repeat for topgallant mast. Tom Quote Link to comment Share on other sites More sharing options...
Admiral Beez Posted March 2 Author Share #125 Posted March 2 16 hours ago, TomRigg said: Maybe too late into your build with the masts made up. But looking at the way that machine works could you do both sides at once? E.g. Lower mizzen shrouds onto mizzen mast looped over at the top . Then fix fighting top and topmast. Then repeat for topgallant mast. Tom I was thinking that too. I have to cut the top in order to separate the two sides, but I can tie it together at the mast head. Quote Link to comment Share on other sites More sharing options...
TomRigg Posted March 2 Share #126 Posted March 2 If you don't cut at position 'Z' in the instructions and loop that through below the fighting top would that do it? Tom Admiral Beez 1 Quote Link to comment Share on other sites More sharing options...
Admiral Beez Posted March 3 Author Share #127 Posted March 3 17 hours ago, TomRigg said: If you don't cut at position 'Z' in the instructions and loop that through below the fighting top would that do it? Tom I shall give that a go. Before I string in the horizontal threads I will first check alignment with the holes in the chain whales. TomRigg 1 Quote Link to comment Share on other sites More sharing options...
Admiral Beez Posted March 8 Author Share #128 Posted March 8 (edited) Before I try the shroud tool again I've decided to install the deadeyes to the chain whales, so that they'll serve as a guide for shroud alignment. The deadeyes are all painted and clear coated. The outward face has simulated rope, the backside is flat. My plan is to glue the shrouds behind the deadeyes (as per the Heller instructions) and then paint the portion between the deadlines with the tan colour used for running rigging (see HMS Victory below). At this scale I think I'll be happy with that. Edited March 8 by Admiral Beez Quote Link to comment Share on other sites More sharing options...
Admiral Beez Posted March 11 Author Share #129 Posted March 11 (edited) Deadeyes now in place. I clear coated them and added a black wash to bring out the rope look. Edited March 11 by Admiral Beez Quote Link to comment Share on other sites More sharing options...
Admiral Beez Posted Friday at 12:31 AM Author Share #130 Posted Friday at 12:31 AM (edited) I’ve decided to not use the Heller shroud tool and instead thread them myself. Here’s today’s update. Disregard the forestays, those are just temporary to prevent the shrouds from pulling the masts backwards during installation. Edited Friday at 04:08 PM by Admiral Beez shipman, robdurant and ccoyle 3 Quote Link to comment Share on other sites More sharing options...
