Pat, think a jig like this will work.



On the other hand, I wonder whether a simple (but dimensionally precise) mock-up of the mast-head wouldn't be sufficient. The cheeks could be held temporarily in place with pins driven through the holes. This would then ensure a tight fit to the mast-head.

wefalck



panta rhei - Everything is in flux





M-et-M-72.jpg  Banner-AKHS-72.jpg  Banner-AAMM-72.jpg  ImagoOrbis-72.jpg
Posted

I agree with Wefalck.  Well done on the jig, Pat.  That is so much better than what I usually do which is use small strips of duct tape to hold down the pieces I'm soldering.  Here's how neanderthals in Texas do it!


Posted

Some clever soldering solutions going on here. The original builder of the 'Herzogin Cecilie' that I'm working on at the museum had an idea - he made the lower masts of brass, so all the subsequent brass parts are simply soldered on.



John

Posted (edited)

Thanks @wefalck, @Glen McGuire and @Jim Lad, appreciate the feed back.  Eberhard, I did have the same idea but using the actual mast.  That is pin and glue the cheeks in place first, but with the very small items I was concerned about keeping the tops of the trestletrees parallel and exactly aligned.  This jig at least keeps one of these variables (spacing) under control, and with a bit of care should be able to control the parallel aspect.  The central spacer is exactly the width of the masthead BUT, there is a tiny bit of 'slop' in the hound/cheek slots, so I may have to seriously reconsider your idea.



Glen one of the three key 'bodging' tools - duct tape, 16 gauge fencing wire and a big hammer.   I may have to resort to duct tape if all else fails ;) - then again I could get those pesky penguins to hold it in place if Keith will spare a couple - yeah I know 🤐



John, if I hadn't already made the masts that could have been an serious option to consider; thanks for the idea.



cheers



Pat
