1/1200 Vigilant Class Brig - The Yards

My work on the smaller scale continues and today I am going to discuss the yards.



Unfortunately I don't have much in the way of pictures because taking them in the middle of building is really difficult at this scale. So instead I am going to use some diagrams to demonstrate and then show a picture of the finished product. First I took a look at some maritime paintings to pick a sail layout. It is important to plan out exactly what you are planning to do as this will impact the position of the yards and we want to produce a coherent model.



After cutting the various thicknesses of brass rod to size, I filed a notch in the middle of each yard to help hold it in the right place. For the gaff and the boom, instead of a notch I used a pair of plyers to squeeze flat one end.

I then super glued the yards in place and tied them to the mast with 10/0 fly tying thread. Though this is not a perfect solution, I have found that this is the best way (where I don't have access to soldering) to secure them to the mast and better to do it now then have them constantly falling off while painting. As you will see in the final picture, it is not really noticeable. I first do a single knot at the front and then run the thread under the opposite sides of the yards from which it came and do a single knot secured with super glue at the back. Then after it is all dry I cut off the ends with a fresh scalpel blade.

For the gaff and boom I used the flattened area which was now a bit wider to tie on with a single knott (and secured with glue) some more 10/0 fly tying thread. The ends of this were then tied around the mast and both the connection and the knot secured with glue.

And here is the finished product ready for basing. The masts are only loosely in place as they will be painted separately before being attached once I have finished painting the deck details. I have chosen to depict her broad reach with the wind on her larboard beam.
